General :
Frequency range
| Tx |
: 156.025 – 157.425 MHz |
| Rx |
: 156.050 – 163.275 MHz |
| Usable channels |
: USA, CAN, INT, WX channels |
| Type of emission |
: 16K0G3E, 16K0G2B |
| Current drain |
(at 13.8V DC) |
| Tx |
: 5.5A (at 25W output) |
| Rx |
: 1.5A (at AF max.) |
| Operating temperature range |
:(–20°C to +60°C)(–4°F to +140°F) |
| Antenna impedance |
: 50Ω (SO-239) |
| Dimensions (W×H×D) |
: 153×67×133mm |
| Projections not included) |
: 61⁄32×25⁄8×51⁄4 in. |
| Weight (approx.) |
: 825g; 1.8lb |
| NMEA formats |
: (NMEA version 2.0 or 3.01) |
| |
(RMC,GGA,GNS,GLL) |
Transmitter
| Output power |
: 25W or 1W (at 13.8V DC) |
| Modulation system |
: Variable reactance frequency modulation |
| Max. freq. deviation |
: ±5 kHz |
| Frequency error |
: ±10ppm |
| Spurious emissions |
: Less than –70dBc (at 25W) |
| Adj. channel power |
: More than 70dB |
| Audio harmonic distortion |
: Less than 10% (at 60% dev.) |
| Residual modulation |
: More than 40dB |
Receiver
| Intermediate freq |
: 1st 21.7 MHz, 2nd 450 kHz |
| Sensitivity |
: 0.22μV typical at 12dB SINAD |
| Squelch sensitivity |
: Less than 0.22μV |
| Adj. Ch. selectivity |
: More than 70dB |
| Spurious response |
: More than 70dB |
| Intermodulation |
: More than 70dB |
| Hum and noise |
: More than 40dB |
| Audio output power |
: 4.5W typical at 10% distortion with a 4Ω load |
