The ALDIS CXD8 Day Light Signal (CXD8 Lampu Isyarat Siang) is a marine navigation light device designed to provide high-intensity visual signals in both daylight and nighttime conditions. This product helps vessels carry out long-distance optical communication, especially when radio, electronic communication systems, or other navigation devices are not in use or are experiencing interference.
With a light intensity of up to 60,000 candela and a visibility range of more than 2 nautical miles, the ALDIS CXD8 is an important choice for navigation safety and communication needs on vessels measuring 50 meters or more in length.
The ALDIS CXD8 is a navigation signal light that uses a tungsten halogen lamp as its light source, with a G6.35 lamp holder. This system produces a directional beam of light through a narrow beam angle of 6°, allowing the light to be clearly visible from a distance.
This lamp is installed as a visual communication device on vessels. The operator can direct the beam toward other ships, port installations, pilot boats, or specific observation points to send signals using light flashing methods, including Morse code when necessary.
In operation, the ALDIS CXD8 has two lamps within its unit:
One lamp serves as the primary light source.
One lamp is available as a backup.
The presence of this backup lamp is important for maintaining operational continuity. If the primary lamp becomes damaged or reaches the end of its service life, the crew can immediately switch to the backup lamp without having to completely halt the signaling function.
Using the CXD8 daylight signal lamp provides a number of important benefits for maritime safety and vessel operational activities.
The ALDIS CXD8 can be used to convey visual messages to other vessels in the surrounding waters. This system is especially useful when radio communication is ineffective, radio frequencies are congested, or communication procedures require the use of light signals.
Visual signals can also be used to give attention signals, navigation instructions, notifications of specific conditions, or limited communication between crew members and parties on shore.
Not all signal lamps are capable of producing a clear light when exposed to direct sunlight. The ALDIS CXD8 is designed as a daylight signal — a high-intensity lamp that remains recognizable in bright conditions.
An intensity of up to 60,000 cd helps the light beam penetrate strong ambient lighting conditions. As a result, the lamp can be used more optimally for daytime sailing activities, especially when the vessel is in open seas, port areas, busy waters, or high-traffic shipping lanes.
Fast and clear communication is an important part of vessel safety. A navigation signal lamp can serve as a supporting communication tool when a vessel needs to give warnings, request attention, or send signals to other vessels.
The ALDIS CXD8 can help support vessel preparedness in facing various situations, such as:
Communication during emergency conditions.
Coordination with other vessels in the waters.
Sending signals to pilot boats or port officials.
Use as a backup communication tool when the radio malfunctions.
Optical signaling needs in certain maritime operations.
Reliability is a key factor in selecting vessel equipment. The ALDIS CXD8 is already equipped with two internal lamps with 24V/60W specifications — a primary lamp and a backup lamp.
This configuration reduces the risk of operational disruption caused by light source failure. The crew can carry out replacement or switch to the backup lamp more quickly when needed.
The marine environment poses heavy challenges for electronic and electrical devices. High humidity, salt water, engine vibration, changing weather, and the risk of corrosion can accelerate damage to equipment not specifically designed for marine applications.
The ALDIS CXD8 uses aluminum, which is relatively strong and suitable for vessel equipment needs. This product also has an IP44 protection rating, which helps protect components from solid objects of a certain size and water splashes from all directions.
In addition, the lamp body uses quality material with a powder-coated surface to support durability in harsh environments potentially exposed to moisture, vibration, and corrosion.
The ALDIS CXD8 Day Light Signal can be used on various types of vessels that require a long-distance light communication system. This product is suitable for vessels measuring approximately 50 meters or more in length.
Some common uses of this daylight signal lamp include:
Commercial and cargo vessels.
Tanker vessels.
Passenger vessels.
Large tugs or tugboats.
Offshore work vessels.
Patrol vessels.
Vessels supporting the maritime industry.
Vessels operating in ports, coastal waters, or open seas.
On vessels, the ALDIS lamp is usually placed in an area with a wide field of view that is easily accessible to the operator, for example around the bridge. Proper placement helps the operator direct the beam accurately toward the vessel or object that is the target of communication.
The ALDIS CXD8 has a number of characteristics that support its use for maritime navigation and communication applications.
This lamp produces a light intensity of up to 60,000 cd with a 6° beam angle. The narrow beam angle produces a more directional beam, helping the operator direct the signal toward a specific target.
Visibility of more than 2 nautical miles makes this product relevant for visual communication within a vessel's operational range.
The ALDIS CXD8 is designed with a wide input voltage to support the needs of various projects and regions. This flexibility helps integrate the device with different vessel electrical systems, with a 24V/60W lamp specification.
Before installation, ensure that the vessel's electrical system, cable connections, electrical protection, and installation procedures have been checked by a competent technician.
This product is stated to feature a constant current and constant voltage LED driver with overload protection and an EOL (end-of-life) function. These protection features are designed to support the reliability of the lighting system and help maintain device operation during certain electrical conditions.
With an aluminum body and a weight of approximately 7.5 kg, the ALDIS CXD8 offers a solid construction for use in the vessel environment. The aluminum material also helps keep the device sturdy without adding excessive load to the mounting structure.
This product has HS Code 940561, which can help with goods identification for trade administration, procurement, and import activities in accordance with applicable procedures.
This product originates from China and can be considered as part of the procurement of vessel navigation and visual communication equipment.
The following are the main specifications of the ALDIS CXD8 Day Light Signal:
Product name: ALDIS CXD8 Day Light Signal.
Product type: Daylight signal lamp or marine navigation signal lamp.
Lamp voltage and power: 24V/60W.
Light source: Tungsten halogen lamp.
Lamp holder: G6.35.
Number of internal lamps: Two lamps, consisting of a primary lamp and a backup lamp.
Visibility: More than 2 nautical miles.
Light intensity: 60,000 cd.
Light beam angle: 6°.
Protection rating: IP44.
Material: Aluminum.
Weight: 7.5 kg.
HS Code: 940561.
Country of origin: China.
Application: Vessels measuring 50 meters or more in length.
To ensure the ALDIS CXD8 operates optimally, routine maintenance needs to be carried out as part of the vessel's equipment maintenance procedures.
Periodically inspect the physical condition of the lamp body, especially after the vessel operates in bad weather or in waters with high salt water exposure.
Clean the exterior of the device of salt, dust, and dirt that can interfere with performance or accelerate corrosion.
Ensure the lens and light path remain clean so that signal intensity does not decrease.
Check the condition of the primary and backup lamps on a scheduled basis.
Ensure cable connections, terminals, and the electrical system are not loose or damaged.
Use replacement lamps with the correct specifications, namely 24V/60W with a G6.35 holder.
Have installation, inspection, and repairs carried out by an experienced vessel electrical technician.
Keep inspection and lamp replacement records to support the vessel's preventive maintenance program.
If you need the ALDIS CXD8 Daylight Signal Lamp for a vessel, maritime project, navigation equipment procurement, or visual communication needs at sea, contact our team for product availability information and price offers.
To place an order, contact WhatsApp 081586838888 or visit our official website for special pricing:
Our address:
Perkantoran, Jl. Taman Palem Mutiara No. 1 Blok A18, RT.7/RW.14, Cengkareng Timur, Kecamatan Cengkareng, Kota Jakarta Barat, Daerah Khusus Ibukota Jakarta 11730.
What is the ALDIS CXD8 Day Light Signal?
The ALDIS CXD8 Day Light Signal is a high-intensity marine navigation signal lamp used for visual communication in both daylight and nighttime conditions. This lamp helps vessels send light signals to other vessels or relevant parties in the sailing area.
What is the main use of the CXD8 daylight signal lamp?
Its main use is as a tool for visual communication between vessels, a backup signaling tool when radio communication is disrupted, and a supporting device for navigation safety at sea.
Can the ALDIS CXD8 be used during the day?
Yes. The ALDIS CXD8 is designed as a daylight signal with an intensity of up to 60,000 cd, so its beam can be seen more clearly in daytime lighting conditions.
What is the visibility range of the ALDIS CXD8?
The ALDIS CXD8 has a visibility of more than 2 nautical miles. The effective distance in the field can be affected by weather, fog, rain, waves, viewing direction, and ambient light conditions.
What is the lamp power of the ALDIS CXD8?
The lamp used has a specification of 24V/60W.
What type of lamp is used in the CXD8?
The ALDIS CXD8 uses a tungsten halogen lamp with a G6.35 holder.
Is a backup lamp available inside the unit?
Yes. Inside the ALDIS CXD8 there are two lamps — one for primary use and one as a backup.
Is the ALDIS CXD8 durable for the vessel environment?
This product uses aluminum, has a construction designed for the marine environment, and an IP44 protection rating. However, periodic inspection, cleaning, and maintenance are still required to keep its performance intact.
What type of vessel is suitable for the ALDIS CXD8?
The ALDIS CXD8 is suitable for vessels measuring 50 meters or more in length, such as cargo vessels, tankers, passenger vessels, patrol vessels, large tugs, and vessels supporting maritime operations.
