The Alinco DJ-CRX5 is a dual-band handheld two-way radio designed to provide stable, clear, and practical radio communication in a wide range of working conditions. Its VHF and UHF frequency support makes it a flexible choice for amateur radio users, construction project coordination, security teams, event organizers, industrial operations, and other field communication needs.
With a transmit power of up to 5W on the VHF band and 4W on the UHF band, the Alinco DJ-CRX5 helps teams maintain coordination across large work areas. The radio also features a compact and rugged design, making it comfortable to carry and ready for demanding field activities that require reliable communication equipment.
One of the main advantages of the Alinco DJ-CRX5 is its dual-band capability. Users can receive and transmit communications across the VHF frequency range of 136–174 MHz and the UHF range of 400–438 MHz. This flexibility allows users to adjust their communication channels according to operational needs and applicable frequency regulations.
The Alinco DJ-CRX5 also supports Wide and Narrow FM through F3E modulation. These bandwidth options allow users to adjust communication quality and efficiency according to the channel being used. Frequency stability of up to ±2.5 ppm further supports consistent communication.
For monitoring purposes, the radio includes an FM broadcast receiver covering the 76–108 MHz range. This additional feature allows users to listen to FM broadcasts when the device is not being used for primary communication coordination.
On the transmitter side, the Alinco DJ-CRX5 offers several output power options: 5W for VHF, 4W for UHF, as well as low-power settings of 2W and 1W. These power settings allow users to select the appropriate transmit level for their needs.
High power can be used when a wider communication range is required, while lower power is useful for conserving battery life when communicating over shorter distances. This flexibility is especially helpful for all-day operations.
The radio features frequency deviation settings of ±5 kHz and ±2.5 kHz, with spurious emissions of up to ≤ -60 dB. These specifications support well-controlled voice transmission and help minimize unwanted emissions.
The Alinco DJ-CRX5 uses a direct-conversion receiver system with a sensitivity of -12 dBu in Wide mode and -9 dBu in Narrow mode. This combination is designed to help optimize signal reception according to the selected communication mode.
For audio performance, the device provides audio output of up to 1W. Its powerful audio output helps users hear messages more clearly, particularly in noisy environments such as construction sites, warehouses, outdoor areas, and event venues.
Good receiver performance and clear audio make communication between team members more efficient. Instructions can be delivered quickly without relying on cellular communication, which may be affected by weak signals or mobile data limitations.
The Alinco DJ-CRX5 measures approximately 118 × 61 × 40 mm and weighs approximately 250 grams. Its compact size makes it easy to carry in the hand, on a belt, in a work bag, or with other team operational equipment.
This radio uses a 7.4V battery and is designed to operate at temperatures ranging from -20 to +55°C. This operating range makes the Alinco DJ-CRX5 suitable for various environments, including both indoor and outdoor work.
In addition to the standard charger, the Alinco DJ-CRX5 battery can be charged from a 12V DC power source using the optional Alinco EDC-198 cable. This feature is particularly useful in vehicles, operational cars, or emergency situations where access to AC power is limited.
The Alinco DJ-CRX5 can serve as a communication solution for various sectors, including:
Building, residential, shopping mall, and industrial area security teams.
Construction projects requiring fast coordination among workers.
Event organizers coordinating committees, technicians, security personnel, and performers.
Warehouse, logistics, manufacturing, and industrial facility operations.
Amateur radio communities looking for a practical dual-band handheld radio.
Operational vehicles with access to 12V DC charging.
Internal team communication in areas with limited cellular coverage.
The use of radio frequencies must comply with applicable regulations and licensing requirements. Make sure that the selected frequencies and channels are appropriate for your operational needs and comply with the regulations in your area.
The Alinco DJ-CRX5 has reception frequencies of 136–174 MHz and 400–438 MHz, along with an additional FM broadcast reception range of 76–108 MHz. Its transmission frequency ranges are 136–174 MHz and 400–438 MHz.
The device uses F3E modulation for both Wide FM and Narrow FM, with frequency stability of ±2.5 ppm. It operates with a 7.4V battery, measures 118 × 61 × 40 mm, and weighs approximately 250 grams.
The transmitter provides output power of 5W on VHF, 4W on UHF, and additional 2W and 1W modes. The receiver uses a direct-conversion system, with sensitivity of -12 dBu in Wide mode and -9 dBu in Narrow mode, and audio output of up to 1W.
Looking for a compact, durable dual-band handheld radio that supports efficient communication? The Alinco DJ-CRX5 can be an excellent choice for supporting smooth team coordination.
For orders, stock availability, and special price offers, contact us via WhatsApp at 081586838888. You can also visit our official websites: alnindo.com and alnindo.id.
Our address:
Perkantoran, Jl. Taman Palem Mutiara No. 1 Blok A18, RT. 7/RW. 14, Cengkareng Timur, Kecamatan Cengkareng, Kota Jakarta Barat, Daerah Khusus Ibukota Jakarta 11730, Indonesia.
The Alinco DJ-CRX5 is a dual-band handheld two-way radio that supports VHF and UHF frequencies for amateur radio and professional communication needs.
The Alinco DJ-CRX5 provides output power of up to 5W on VHF and 4W on UHF. It also offers 2W and 1W power settings for more efficient battery use.
Yes. This handheld radio is suitable for coordination in construction projects, security teams, events, warehouses, industrial facilities, and other internal team communication activities.
Yes. In addition to receiving VHF and UHF frequencies, the Alinco DJ-CRX5 supports FM broadcast reception in the 76–108 MHz range.
Yes. In addition to the standard charger, the battery can be charged from a 12V DC power source using the optional Alinco EDC-198 cable, making it practical for use in vehicles or emergency situations.
